SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer

Discontinued

1 7

SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer

Name: SC9120LBL - BRK Hardwired Combo smoke & CO alarm with 10-Year sealed 9V lithium battery backup. | BRK
Brand: Hotfix-Brkelectronics

SKU: SC9120LBL

Hardwired Combo smoke & CO alarm with 10-Year sealed 9V lithium battery backup. AC 120V Interconnectable with Silence and Latching features. Includes Ionization smoke sensing tehcnology and electrochemical carbon monoxide sensor.

Additional Options

Product variants

View Replacement Products

RESOURCES |
SPECIFICATIONS |
OVERVIEW |
REPLACEMENT PRODUCTS |
WORKS WITH |
YOU MAY LIKE
ACCESSORIES |

Resources

Sell (0)

Install (0)

SC9120LBL User's Manual 01/2015 1.2 MB Download

SC9120LBL User's Manual (Spanish) 01/2015 1.23 MB Download

SC9120LBL Specification Sheet 10/2014 0.4 MB Download

More Information on Ionization vs. Photoelectric Smoke Alarms 01/2023 - Download

Audio Files (0)

Specifications

BRK Model

SC9120LBL

Replacement Model

SMICO105-AC

Type

Combination Smoke & Carbon Monoxide Alarm

Sensor Type

Ionization

Sensor Information

Smoke particles of varying number and size are produced in all fires. For maximum protection, use both ionization and photoelectric sensing technologies. Ionization alarms are generally more sensitive to fast flaming fires and photoelectric alarms are generally more sensitive to smoldering fires.

Power Source

Hardwired

Current Type

AC; DC

Battery Backup

Yes

Backup Battery Type

Lithium

Hardwired Interconnectivity

Yes

Sound Level

85dB at 10 feet

Product Height

5.69

Product Length

2.25

Product Width

5.69

Product Weight

0.66

Warranty

10 Years Limited

Features

Battery Backup; End-of-Life Warning

Ambient Operating Temperature (Min)

40 °F; 4 °C

Ambient Operating Temperature (Max)

100 °; 38 °C

Ambient Relative Humidity (Min)

10% (RH)

Ambient Relative Humidity (Max)

95% (RH)

Approvals and Standards

Listed to UL 217 Standard; Listed to UL2034 Standard

UPC Case

20029054015376

UPC Number

029054015372

Product Overview

Batterie de secours au lithium d'une durée de vie de 10 ans
Tiroir de batterie verrouillable
Indicateur d’alarme à verrouillage : mémorise l’unité à l’origine de l’alarme
Test/silence à bouton unique
La technologie Intelligent Sensing Technology™ contribue à réduire le nombre de fausses alarmes
Fixation parfaite – permet un alignement facile de l’alarme

Replacement Products


SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer
