9120LBL BRK 120V AC/DC Smoke Alarm - 10YR Lithium Battery - Locked Battery Drawer

Discontinued

1 7

9120LBL BRK 120V AC/DC Smoke Alarm - 10YR Lithium Battery - Locked Battery Drawer

Name: 9120LBL - Ionization hardwired smoke alarm with 10-Year sealed 9V lithium battery backup. | BRK
Brand: Hotfix-Brkelectronics

SKU: 9120LBL

Hardwired smoke alarm with 10-Year sealed 9V lithium battery backup. AC 120V Interconnectable with Silence and Latching features. Includes Ionization smoke sensing technology.

Additional Options

Product variants

View Replacement Products

RESOURCES |
SPECIFICATIONS |
OVERVIEW |
REPLACEMENT PRODUCTS |
WORKS WITH |
YOU MAY LIKE
ACCESSORIES |

Resources

Sell (0)

Install (0)

9120LBL User Manual 01/2015 1.06 MB Download

9120LBL Spanish User Manual 01/2015 1.02 MB Download

9120LBL Specification Sheet (English) 01/2014 0.39 MB Download

More Information on Ionization vs. Photoelectric Smoke Alarms 01/2023 - Download

Audio Files (0)

Smoke Alarm - Alarm Sound - 9120LBL 06/2023 0.11 MB Download

Low Battery Sound - 9120LBL 06/2023 0.02 MB Download

Specifications

BRK Model

9120LBL

Type

Smoke Alarm

Sensor Type

Ionization

Sensor Information

Smoke particles of varying number and size are produced in all fires. For maximum protection, use both ionization and photoelectric sensing technologies. Ionization alarms are generally more sensitive to fast flaming fires and photoelectric alarms are generally more sensitive to smoldering fires.

Sound Level

85dB at 10 feet

Product Height

5.69

Product Length

2.25

Product Weight

0.61

Product Width

5.69

Power Source

Hardwired

Operating Voltage

120V AC 60Hz w/ 9V lithium battery backup

Hardwired Interconnectivity

Yes

Wireless Interconnectivity

Battery Backup

Yes

Backup Battery Type

Lithium

Backup Battery Size

Backup Battery Life

10 Years

Color

White

Ambient Operating Temperature (Min)

40 °F; 4 °C

Ambient Operating Temperature (Max)

100 °F; 38 °C

Operating Relative Humidity (Min)

10% (RH)

Operating Relative Humidity (Max)

95% (RH)

UPC Case

20029054015369

UPC Number

029054015365

Warranty

10 Years Limited

Features

Battery Backup; Hardwire Interconnectivity

Approvals and Standards

Listed to UL217 Standard

Product Overview

La batterie de secours au lithium d'une durée de 10 ans permet d'économiser du temps et de l'argent sur les coûts d'entretien annuels
Tiroir de batterie verrouillable
Indicateur d’alarme à verrouillage : mémorise l’unité à l’origine de l’alarme
Technologie intelligente : contribue à réduire le nombre de fausses alarmes
Fixation parfaite – permet un alignement facile de l’alarme
Test/silence à bouton unique
